Description
The design of the Edge® 3 is for the most advanced power chair experience ever! Upgraded SRS (Smooth Ride Suspension) provides a smooth, comfortable ride with advanced stability. Optional iLevel® is available at 7 km/h with up to 12″ of power adjustable seat height. Standard features include front and rear LED fender lights, a USB charger, and drive wheel colour accents. The Edge® 3 is available in a total of 20 colour options, including seven brand-new, bold colours.
Edge 3 Features
- Upgraded SRS (Smooth Ride Suspension)
- Optional 7 km/h with iLevel®
- Optional iLevel’s patented Extra Stability Technology® enhances safety while performing transfers, reach, and numerous other activities of daily living
- iLevel is retrofittable on the Edge 3
- Fender lights, USB charger, and drive wheel colour accents included
- 7 bold new colours and a total of 20 colour options
- Made in America of foreign and domestic parts
- Available with WC19 crash-test approved occupied transit kit option with captain’s seating, Synergy® seating, and TRU-Balance® 3 seating configurations.
Specifications
| Model | Q6 Edge 3 |
| Drive Wheels | 14″ solid Optional: 14″ pneumatic |
| Caster Wheels | Front: 6″ solid Rear: 6″ solid |
| Maximum Speed4 | Up to 10 km/h Up to 7 km/h with iLevel activated |
| Ground Clearance | 2.7″ (battery tray) |
| Turning Radius5 | 20.5″ |
| Overall Length | 32.23″ without front riggings |
| Base Width | 24.4″ |
| Seating Sizes | Synergy®/TRU-Balance® 3 Static Seat: W: 10-22″; D: 10-22″ TRU-Balance® 3 Power Tilt: W: 12-22″; D: 12-22″ TRU-Balance® 3 Tilt and iLevel®: W: 12-22″; D: 12-22″ TRU-Balance® Flex Seating: W: 15-22″; D: 15-20″ |
| Seat-to-Floor Heights16 | Synergy®/TRU-Balance® 3 Static Seat: 16.5-18.5″ TRU-Balance® 3 Power Tilt: 17.5-19.5″ TRU-Balance® 3 Tilt and iLevel®: 17.5-19.5″ TRU-Balance® Flex Seating: 16.5-19.5″ |
| Manual Recline10 | Yes |
| Battery Size6 | NF-22 (2) |
| Battery Weight14 | 38 lbs. each |
| Available Electronics12 | 120A Q-Logic 3 EX 75A Q-Logic 2 NE 75A Q-Logic 2 NE+ |
| Battery Charger | 8A off-board |
| Motor Packages | 2-Pole, Mid-Wheel 6® |
| Weight Capacity7 | 300 lbs. |
